Inline Combi 50/55 Filter Red Label Excl. Filter Media - Aquaking

Inline Combi 50/55 Filter Red Label excl. filter media – AquaKing

The Inline Combi 50/55 Filter Red Label from AquaKing is a professional and fully automatic pond filter system, developed for larger ponds and koi ponds where high flow rates, reliability and minimal maintenance requirements are essential. Thanks to the innovative inline filter design, this system offers highly efficient water flow and a compact, easy-to-manage installation.

This version is supplied excluding filter media, allowing you to fully configure the filter system according to your own judgment based on pond volume, fish stock and desired filtration capacity.

Two versions: Gravity & Pump
The Inline Combi 50/55 Filter Red Label is available in two versions:

• Gravity version – for gravity-fed pond systems

• Pump version – for pump-fed installations

After purchase, we will contact you to agree on which version (Gravity or Pump) you would like to receive. This makes the filter flexibly deployable and suitable for virtually any pond setup.

INLINE COMBI technology
The INLINE COMBI series features filter chambers arranged in a single line. This design:

• Optimises water flow

• Reduces resistance in the filter system

• Makes the filter highly suitable as a replacement for traditional room filters

Automatic drum filtration
At the heart of the system is a drum filter with a 120 micron drum screen, which effectively removes fine dirt particles from the pond water.
The internal wash pump fully automatically cleans the drum as soon as dirt is detected. The double brush system keeps the waste collection trough clean and reduces manual maintenance to a minimum.

Freely configurable biological filtration
Behind the drum filter are spacious filter chambers for biological filtration, such as a moving bed and additional filter media. Because this version is supplied excluding filter media, you determine the composition of the filter system yourself.

Built-in UV-C disinfection
The integrated 80 Watt INOX UVC unit combats algae, bacteria and fungi and contributes to clear and healthy pond water. External UV equipment is therefore unnecessary, which benefits the flow rate.

Durable and low maintenance
The Inline Combi 50/55 Filter Red Label is equipped with:

• A newly patented sealing system that prevents UV damage

• Low water protection for extra safety

• A robust Red Label construction for long-term intensive use

Main features

• Fully automatic drum filter

• Inline filter design for optimal flow

• Drum screen with 120 micron mesh size

• Built-in 80 Watt INOX UVC unit

• Internal wash pump

• Double brush system

• Low water protection

• Available as Gravity or Pump (choice after purchase)

• Excluding filter media

• Suitable for large ponds and koi ponds

• 2-year factory warranty (excluding screen panels and UVC replacement parts)

Technical specifications

• Dimensions (L × W × H): 2172 × 850 × 1005 mm

• Panel size: 400 × 650 mm

• Drum screen: 120 micron

• Inlets: 7 × 110 mm

• Outlets: 4 × 110 mm

• Wash pump: internal Q800103

• UVC unit: 80 Watt INOX
